General:

Lifting height

3,845 mm

Wheelbase

3,000 mm

Ground clearance

407 mm

Chicken corner

45°

Breakout force (bucket cylinder)

123 kN

Nominal load

 kg

Kipload, straight

8,899 kg

Tipping load, maximum steering angle

 7,714 kg

Max. Steering angle articulated steering

40°

Diesel engine:

Manufacturer

Deutz

Model

TCD6.1

Type

6 cylinder, with common rail injection, water-cooled

Emission standard

Stage V

Nominal power

 129 kW / 2,200 rpm

Fan

Hydraulically driven cooling fan with manual reversing

Hydraulic system:

Main pump(s)

Axial piston pump with load-sensing control

Brand of main pump(s)

Kawasaki

Max. Oil Flow

220 l/min

Additional function

3rd Function, joystick control

Transmission and axles:

Drive

Hydro-dynamic drive with torque converter

Brand axles and transmission

Dana

Max. driving speed (forward)

40 km/h

Gears forward

4 forward gears with automatic function

Reverse gears

3 Gears

Front axle

Front axle with manual differential lock (100%)

Rear axle

Rear axle oscillation 12°

To change gear

Forward/backward switch on joystick

Kick-down function

Automatic

Brakes

4-wheel braking via multiple wet disc brakes

Parking brake

Mechanical

Tires and wheels:

Tire size

20.5 R25

Rims

3-piece rims

Loading frame:

Kinematics

Z

Quick change

Hydraulic, ISO

Relief:

Standard

Road lighting

Cabin front

2 work lights

Cabin rear

2 work lights

Flashing light

1x Orange
